Interviews: Principal Engineer Al Bradley
Interview by Lonny Lippsett and Sharon Franks
Bradley in his office surrounded by models of some of the toys he invents to help scientists solve problems.
Question: A toy maker?
Al: I have a hypothesis that playing with toys is a fundamental
evolutionary instinct. It teaches you what youre good at,
what your brain will be successful at. So I played with Tinker Toys
and Erector Sets and radio kits. I was a compulsive gadget-builder.
I knew that I had to study engineering.
11 years old, Al Bradley and a friend tried to make a submarine
out of wood. Here, Al tries it out for size.
Question: So why didnt you end up building bridges or cars, for example?
Al: At age 10, I saw two absolutely pivotal moviesJacques
Cousteaus first color movie, The Silent World,
and Walt Disneys 20,000 Leagues Under the Seaand
I just totally fell in love with the idea of going under water.
I spent my youth trying to build submarines.
Question: Did you build any?
Al: At age 11 I tried to make a submarine out of wood.
My father was very wise. He said, If you can keep the water
out of this for 15 minutes, Ill let you get in it and try
it. My dad knew I couldnt succeed at age 11 to make
a waterproof hull. The submarine was ridiculous. It was L-shaped,
so you could sit up in it. But we had a lot of fun.
Question: Did you actually test it?
Al: Well, I put it in the water and watched the water
flow in through the quarter-inch gaps where the boards met. The
experience taught me how to saw a straight line.
Question: And you tried again?
Al: Oh yes. In college I had a project to make a two-man
wet sub. How to make the propulsion system was beyond me at the
time, however. So the sub had wooden flippers that looked like frog
legs. It ended up as a playground toy in a pre-school.
Question: And after college?
Al: Then I discovered that engineers could work with
ocean instruments. I got a summer job at Woods Hole Oceanographic
Institution. I found out that the worlds top oceanographers
chose to spend their coffee breaks in the galleys of the ships,
shooting the breeze with the stewards, the able-bodied seamen, the
captains, and the chief engineers. The scientists knew they had
a lot to learn from the ships crews. And the ships crews
were not just bus drivers. They wanted to talk science with the
scientists. That was the mind-set of Woods Hole.
Bradley works at the bench in his lab testing the computer brains of the autonomous underwater vehicle, ABE.
Does it work in a similar way with the scientists and engineers
Al: Its very much a two-way street. The scientists
are driven by curiosity about the universe, about how things work.
The engineers are driven to make things. The scientists want to
find out something, and I bring the world of engineering to bear
on how to build something to get them what they need. The magic
happens where the two worlds meet. The solution usually comes after
many discussions and a long period of gestation.
Question: Did that happen when you developed ABE,
the Autonomous Benthic Explorer?
Al: Oh yes. Thats an interesting story (See Part
II of Als interview tomorrow.)
Question: On this cruise, ABE will be diving in the late
afternoon for 6 to 8 hours and then returning in the early morning.
But you have used ABE for longer stretches, right?
Al: Weve gotten past the milestone of putting ABE
down, leaving it there, going off out of contact, to do an Alvin
dive in another location, and then coming back to retrieve ABE.
Of course, were always nervous when we do that.
Question: Because you dont like to lose your toysespecially
when they are so expensive?
Al: Thats what I do. Im one of the very fortunate
people who can continue to play with toys. And, I believe, they
are quite useful.
Question: How was ABE born?
Al: Originally, Barrie Walden (head of the Alvin Group at WHOI) came to us and said, Half the scientists requests for Alvin dives are to return to look at places where weve already been. Could we build something that descends to the ocean bottom with a weight, finds a sound beacon on the seafloor, takes a picture, drops its weight, and pops up again? Then we could save Alvin for missions that only it could do. We said, OK, sure, but lets think about that. What if this device could hold its position near the seafloor? And what if we give it some minimal thrusters so that it can move horizontally along the bottom? Thats much better, because you could get a series of pictures along a line, not just one picture.
That seemed good, but then we said, OK, lets think some more. If this vehicle can home into a sound beacon, why not have it go out on a line, and then come back and find the beacon againand then go out on another line, like the spokes of wheel, so that you can survey a 50-meter circle at one time? This was an incredible step beyond the first concept of diving down to get one picture, and it wasnt that much more complicated.
|Al Bradley and Dana Yoerger, co-inventors with Barrie Walden of ABE, work together to design underwater vehicles for scientific research.
Question: But apparently you kept on thinking.
Al: Yes, we said, Wait a minute. If we have something that can home into a beacon and maneuver near the seafloor, why dont we just add a latching mechanism, so that it can come back and anchor to the beacon? Then it can shut down, go to sleep, wake up again in an hour, or two days, or a week, and go out and do it all over again. Suddenly we opened up a whole new dimension of possibilities for scientists.
Question: Please explain.
Al: Whenever you put a camera in an interesting place on the seafloor, it gets crudded up with bacteria. And if you put it out in cold water where it wont get crudded up, you dont see anything interesting. Our new thing could go to sleep in cold water, come in to the target site, take a series of photographs, go back out, and sleep in cold water. The goal was to give geologists and biologists a series of photos over timephotos of a field of tubeworms growing, for instance, or a field of black-smoker chimneys growing and decaying. That was the original concept for ABE, and we had never built a device like that before.
Question: But then ABE evolved some more?
Al: We had tested ABE in Woods Hole harbor, but we had to try it out in the deep ocean. So we looked for an opportunity to test it. (WHOI geophysicist) Maurice Tivey took a risk. He was going on cruise to the Juan de Fuca Ridge, and he said. Why dont you come along and try putting my instruments on ABE. Maybe you can use it to get magnetics data for me. But just in case, he also towed a magnetometer and used all the regular devicesjust to make sure he got the information he needed.
Question: How did it go?
Al: Maurice was ecstatic. ABE collected data on the magnetic properties of seafloor rocks that were far superior than what you can get with Alvin. Alvin can collect magnetics data perfectly well. But its ill-suited to that task. To get magnetics data, you need to fly in a perfectly straight line and slightly out of visible contact with the bottom. Alvin pilots prefer not to do that. Alvin is better suited to bring people to the bottom and look at something closely, or to pick up something. Its a waste of Alvins time to just go back and forth, out of visible range of the seafloor. But ABE could do that. It became clear that ABE was a superb surveying tool. So we switched our thinking and said, Dont just put ABE down and dock it. Get that thing right back up to surface after a dive, get out the data, recharge its batteries, and send it back down as fast as you can. That way we could get much more data and cover much more ground.
|ABE, the Autonomous Benthic Explorer, is recovered after a mission to the seafloor.
Question: And youve added other instruments onto ABE so that it can acquire more kinds of information.
Al: Weve added a scanning sonar, so that instead of sending just one ping of sound that bounces off the seafloor, ABE puts down a fan of 25 pings. That allows us to get an image of the seafloor with much more texture. After this cruise, in the 10 days before we leave on our next cruise, we hope to install a multi-beam sonar that sends out 64 or 128 pings, instead of 25 beams. And there are lots of other instruments we want to put on ABE.
Question: What happened to the original plan of docking ABE on the seafloor for long periods of time?
Al: Theres no reason not to go back to the original scenario eventually. We just found that ABE was useful in other ways that we hadnt originally anticipated.
